Freyr HVLS FAN

KARL Freyr PMSM HVLS FAN is a special Big Fan that install in low height installations, brings you comfortable cooling feeling in smaller spaces.

Contact us

TECHNICAL PARAMETER

Model	Motor Power	Size	Max Speed	Air volume	Current	Fan weight	Noise
CTPM-400-4.2	0.4KW	14ft(4.2m)	0-80	10000 m³/min	220V/2.0A	68kgs	43dBA
CTPM-400-3.6	0.4KW	12ft(3.6m)	0-90	9000 m³/min	220V/2.0A	62kgs	43dBA
CTPM-400-3	0.4KW	10ft(3m)	0-100	7500 m³/min	220V/2.0A	52kgs	43dBA

DESCRIPTION

Motor

KARL PMSM motor is researched with Tsinghua

University professor, with specialized winding machine,

complete testing equipment, strict and effective quality

assurance system, can fully ensure low temperature of

inside motor, and guarantee motor temperature.

Maintenance Free

KARL PMSM motor requires no traditional oil changes. No more costly maintenance and leakages.

VFD

Simple appearance, small structure, small installation volume, saving installation controls; integrated integration, ready for use with on-site wiring, compatible with permanent magnetic synchronous and asynchronous motors.

Fan Blades

KARL fan blades are made of Aluminum6063 high-performance aluminum alloy; the extrusion molding (T6 heat treatment) process and the blades have undergone its own simulation analysis and have unique built-in rib processing. The unique arc design of the fan blades makes the air volume larger and more stable.

Beam connecting part

KARL special design, with 8mm thickness plate, and special bend, robot welding technology, can totally ensure fans safety to avoid any accident happened.

INSTALLATION DRAWING
